Static load test 2,000 kg and grounding test certified by UL listed
Dynamic Load: 1,800 kg / 3,968 lbs.
Improved cable entry via multiple access Points.
Quick release top panel can be easily removed and replaced after cables are installed.
80% open area with our new honeycomb perforation
Split level side panels provide convenient access to installed equipment.
Depth adjustable 19" vertical mounting rails in 6.35 mm increments.
"U" numbers on 19" rails.
Knock down design for efficient shipping.
Simple and quick assembly time, approximately 18 minutes.
Quick release and reversible doors.
Flexible packing methods for convenient stocking and end user delivery.
Multiple sizes available.
Conform to EIA-310E, JEC-60297-2.
Five stage iron-phosphate pretreatment with textured powder coat finish, tested to 500 hours salt spray under ASTM-D610-01 and ASTM-B117.
Standard color is low gloss RAL 9005 black.
Premium grade hot, cold rolled and Galvannealed Steel.
Designed and Manufactured under ISO 9001 and ISO 14001.
All materials RoHS compliant.
