Nvidia MGX Rack (for GB200 NVL72)

Arion rack 600W series: Vendor neutral and highly versatile 19" rack provides quality solutions for a wide variety of IT and Data Center applications. HD top version comes with additional openings on top panel for cable entry.

Disclaimer. All product information and catalogs sheets are updates from time to time and actual product may vary from what is shown.

  • FEATURES
  • STANDARDS & MATERIALS
  • DOWNLOAD

Specifically designed to support Nvidia’s GB200 System, the MGX Rack features:

  • ORV3 44 0U Rack but designed for MGX ecosytem and offerings
  • 600 mm wide by 1068 mm deep by 2236 mm high
  • Bolt on 132 mm deep Extension frame extends overall depth to 1,200 mm.
  • Full length EIA 19″ Mounting Rails
  • 21″ 0U Mounting
  • Blind Mate Ready for Manifolds
  • Front Cabling Zone for large interconnect systems
  • Top Cabling Openings enlarged
  • 1,600 KG Load rated
  • Door and Side Panels available
  • UL listed : UL 2416 Issue No.2, CSA 22.2 No. 60950-1-07
  • Dimensions conform to EIA-310E, IEC-60297-1, 2
  • Five stage iron-phosphate pretreatment with textured powder coat finish, tested to 500 hours salt spray under ASTM-D610-01 and ASTM-B117
  • Standard color is low gloss textured black
  • Premium grade Hot and Cold rolled steel sheet
  • Structure of Frame Top and Frame Boottom are made of SAPH-440 (Automobile grade)
  • Designed and Manufactured under ISO 9001 : 2008 and ISO 14001
  • All materials RoHS compliant

Cheval can provide Nvidia’s MGX OCP rack platform and associated mounting kits :

Item Description Nvidia Part Number Cheval Part Number
1
Nvida MGX Rack
NVOR3M0101
NVOR3M0101
2
ODM Mechanical Component GB200 NVL Leak Detection Tray, MGX Rack
754-24972-0015-000
CVACORV3031
3
ODM Accessories Component GB200 NVL MGX Rack Mounting Kit for CC and Manifold
754-24972-0015-000
CVACORV3032
4
MGX Rack Extension frame 132mm Deep
CVACORV3039
5
MGX Extension Bracket 40mm Deep
CVACORV3050
