The PF-19 Series of rack mounted 19" Enclosures, like its companion SA Series, is designed for both the industrial and home hobbyists. PF-19 is a heavy duty enclosure which can be installed into any standard 19" rack or using the rubber feet provided, set on any surface. The high quality steel body features removable top and bottom panels, which are liberally vented so your components stay cool. The 3.00 mm thick Aluminum front panel is stout but easily worked by the user. Inside front steel plate and multi holed mounting rails, allow for convenient PCB and component installation.
Disclaimer. All product information and catalogs sheets are updates from time to time and actual product may vary from what is shown.
FEATURES
STANDARDS & MATERIALS
DOWNLOAD
Light weight and strong
Very durable all aluminum (AL 5052) construction
Easy to assemble
Extensive top/bottom and side/side ventilation
Inner front panel for component mounting allows outer front panel to remain “clean” appearance.
Two pieces of extruded aluminum component mounting bars for components fixing are included in the basic kit. Additional bars may be ordered as needed.
Optional mounting plates for PCB and heavy components such as transformers
Optional solid side covers for air flow control or decorative look in non 19” rack mounted applications.
19” rack mounted or free standing
Flat pack for efficient storage and shipping
Materials/Finish:
Light weight and strong
Very durable all aluminum (AL 5052) construction
Easy to assemble
Extensive top/bottom and side/side ventilation
Inner front panel for component mounting allows outer front panel to remain “clean” appearance.
Two pieces of extruded aluminum component mounting bars for components fixing are included in the basic kit. Additional bars may be ordered as needed.
Optional mounting plates for PCB and heavy components such as transformers
Optional solid side covers for air flow control or decorative look in non 19” rack mounted applications.
Our SA Series of stand along general use electronic enclosures is highly versatile line of quality enclosures for both industrial and hobby use. The rugged steel body provides easy access to the components being assembled inside. The Aluminum front and rear panels are ideal for end user customization. Available in 24 different sizes and configurations, the SA Series enclosures come flat packed and its unique "snap together" design requires only 4 screws to complete the assembly.
Disclaimer. All product information and catalogs sheets are updates from time to time and actual product may vary from what is shown.
FEATURES
STANDARDS & MATERIALS
DOWNLOAD
Light weight and strong
Very durable all aluminum (AL 5052) construction
Easy to assemble, only 4 screws needed
Extensive top/bottom and side/side ventilation
Two pieces of extruded aluminum component mounting bars for components fixing are included in the basic kit. Additional bars may be ordered as needed.
Flat pack for efficient storage and shipping
Heights from 1.5U to 5U, conform to IEC-60297-1.
Widths of 230mm, 305mm and 432mm
Depths of 178mm and 279mm
Premium grade (AL 5052) aluminum.
Designed and manufactured under ISO 9001:2008 and ISO 14001:2004
The HS-19 Series of rack mounted 19” heatsink enclosures is a versatile and user friendly 19” enclosure series. Designed for both professional users and home hobbyists alike, HS-19 features extruded aluminum heatsink side panels. The high grade aluminum body features removable top and bottom panels providing easy access to work inside.
An inner front panel allows you to mount all your components on it and the 3.00 mm thick Aluminum outer front panel covers it to give your project a professional look. Extruded aluminum component mounting rails are slotted to allow for convenient PCB and component installation. HS-19 is provided with self adhesive rubber feet if rack mounting is not required.
Disclaimer. All product information and catalogs sheets are updates from time to time and actual product may vary from what is shown.
FEATURES
STANDARDS & MATERIALS
DOWNLOAD
Extruded heatsink side panels provide excellent cooling
Inside face of side panels have slot for easy general purpose bar installation
All aluminum construction
Inner front panel for component mounting allows outer front panel to remain “clean” appearance
“Open Frame” design maximizes user convenience for component assembly
Heavy duty handles
Optional mounting plates for PCB and heavy components such as transformers
19” rack mounted or free standing
Flat pack for efficient storage and shipping
Heights from 1U to 6U
Depths of 245mm, 335mm and 425mm
Conforms to IEC-60297-3.
Premium grade aluminum sheet: AL 5052 and extrusion: AA 6063 (Aluminum Alloy).
Designed and manufactured under ISO 9001:2015 and ISO 14001:2015
